CM  Series

Applications and installation

centrifugal pumps with single impeller are able to offer high flow rates, provide smooth, nonpulsating delivery,  and regulate the flow rate over a wide range without damaging the pump.

For the correct functioning of the pump, use clean water, or non-aggressive liquids charged with small solid impurities.

To be used in flow irrigation system in gardening,  agriculture and industrial fittings.

Pumps should be installed in a covered area, protected

against the weather.

Operating limitations

Max ambient temperature up to 40℃

Max fluid temperature up to 80℃

Max pressure up to 10 bar

Construction features

Pump Body: cast iron

Motor Housing: aluminum

Shaft: 45# steel /stainless steel

Impeller: Brass

Motor: closed, externally ventilated

Insulation Class: B/F

Protection Class: IP44 /IP54

Duty: continuously rated

Mechanical Seal: ceramic steatite/ metalized carbon
